If possible please provide the following information:


Detailed Drawing Of Optic

The drawing should have enough information to formulate a quote with accurate tolerances and coating specifications

If You Do Not Have A Drawing Please Provide The Following Information:

Substrate:

Substrate Type

Dimensions

Tolerances

parallelism

Flatness

Flatness Clear Aperture

Surface Quality

Quantity

Coating:

Wavelength Band Of Interest

Transmission Or Reflectivity Specification

Polarization State

Angle Of Incidence

Coating Clear Aperture

Do not have all of the relevant information?

If you do not have all of the relevant information do not hesitate to contact us and we will try and help you "dig" into your requirements and let you know what can be done

Submit Specifications below:
